Yarden VT-2 Vibrating Transducer Speaker
The vibrating transducer converts almost any surface, wall, or table into a quality speaker. It delivers 10W power at 8Ω and features a compact design for versatile under-table, on-wall, or in-wall installation. The selectable line transformer supports 70V/100V operation or 8Ω bypass mode.
- Vibrating Transducer — Nearly any surface, wall, or table becomes a quality speaker.
- Power Rating — 10W @8Ω.
- Very Compact.
- Easy, Versatile Installation — Under the table, on–wall, in–wall.
- Selectable Line Transformer — Choice of 70V/100V using a line transformer, or 8Ω when switching to bypass the transformer.
- Kramer Patent Pending.
| Frequency Response | 20Hz to 3kHz@ −3 dB; 20Hz to 20kHz@ −10 dB |
| Vibrating Transducer Diaphragm | ABS757 118 x 81 mm, 3mm thick |
| Impedance | 8Ω ±15% |
| Transformer Taps | 70V – 6W / 3W / 1.5W; 100V – 6W / 3W / 1.5W |
| Sensitivity | 80dB ±3dB @ 1W−1m |
| Max SPL (7.5W) | Continuous − 90dB; Peak − 93dB |
| Power Handling | 10W RMS; 30W Continuous program |
| Crossover Frequency | 100Hz |
| Directivity Factor (Q) | 6.9, averaged 1kHz to 10kHz |
| Directivity Index (DI) | 8.4 dB, averaged 1kHz to 10kHz |
| Input Connectors | Red/black push-type terminal |
| Materials | ABS757 plastic grille and ABS777B baseplate |
| Operating Temperature | −15° to +70°C (5° to 158°F) |
| Storage Temperature | −30° to +55°C (−22° to 131°F) |
