The video streaming receiver supports up to 4K@60Hz (4:2:0) resolution over a 1G Ethernet network, with unicast and multicast streaming. It features balanced analog audio de-embedding, web-based and front-panel control, Protocol 3000 API support, and RS-232/CEC control gateway functionality. It also supports video walls up to 16×16 and optional Power over Ethernet (PoE) for simplified installation.
- Outstanding end–user experience
- Ideal for large–scale deployments
- Robust security
- Simple planning and rollout
- Supports HDCP 2.2
| Outputs | 1 HDMI: On a female HDMI connector |
| Ports |
2 Ethernet: On RJ−45 connectors 1 Balanced Audio: On a 5−pin terminal block connector 1 RS-232: On a 3−pin terminal block connector |
| Network |
Multicast through RTSP (Real Time Streaming Protocol): IGMP snooping, non–blocking, Layer 2 Unicast Through RTSP (Real-Time Streaming Protocol) Bitrate Peak: 850Mbps, 4K average: 350Mbps, 1080p average: 250Mbps |
| Video |
Compression Standard: JPEG-based, private stream Max Resolution: 4K@30Hz 4:4:4 |
| Video Streaming |
Compression Standard: JPEG2K-based, proprietary stream Max Input Resolution: 4K@60hz (4:2:0) Max Output Resolution: 4K@30hz (4:4:4) Max End-to-End Resolution: 4K@30hz (4:4:4) |
| Audio |
Supported Formats: LPCM, Dolby, and DTS LPCM LPCM upto 7.1/24−bit/192kHz Dolby Dolby Atmos™, Dolby TrueHD, Dolby Digital Plus™, Dolby Digital EX, Dolby Digital 5.1, Dolby Digital 2/0 Surround, Dolby Digital 2/0 Dolby Atmos™, Dolby TrueHD, Dolby Digital Plus™, Dolby Digital EX, Dolby Digital 5.1, Dolby Digital 2/0 Surround, Dolby Digital 2/0 |
