VS-6464DN-EM

VS−6464DN−EM is a high−performance 8x8 to 64x64 modular matrix switcher chassis for AV signals. The unit is a multi−format digital switcher, populated from 8x8 to 64x64 in increments of eight inputs and/or eight outputs. The chassis includes two power supplies with an optional third for redundancy, a control module, and a test module that can monitor and test any input and output in the matrix. VS−6464DN−EM supports a wide variety of input and output cards for different AV signals.

Contact to Seller
  • Max. Data Rate — 6.75Gbps (2.25Gbps per graphic channel) when using compatible cards.
  •  Kramer Network Management — Automatic discovery through the network, FW upgrade management for matrix and cards, identify card type and location and indicate card status(module ID, actual firmware versions), matrix switching, specified card features configuration (for example, volume levels on audio cards), Store and Recall of predefined switching scenarios, integrated Maestro automation, and more.
  •  HDTV Compatible.
  •  HDCP Compliant — With DVI (HDCP) and HDMI modules.
  •  HDMI Support.
Download Product catalog

INPUTS
  • 8 to 64 (in increments of 8) of various inputs
  • See ACCESSORIES & RELATED PRODUCTS

OUTPUTS
  • 8 to 64 (in increments of 8) of various outputs
  • See ACCESSORIES & RELATED PRODUCTS

Video
  • Max. Data Rate: 6.75Gbps (2.25Gbps per graphic channel) depending on the cards used
  • Max. Resolution: Up to UXGA
  • Max. Resolution: 1080p, 1920x1200
  • Standards Compliance: Supports DVI 1.0

CONTROLS
  • Front panel buttons, infrared remote control transmitter (38kHz–modulated), RS–232, Ethernet, mini USB port, in/out audio testing jacks, reset button (for future use)

SWITCHING
  • Confirm or At Once for immediate switching

Power
  • Source: 100–240V AC, 50/60Hz
  • Consumption: 330VA
