USB 3.2 Gen 2 Fiber Optic USB-C Cable (AOC) (356442)

The Manhattan USB 3.2 Gen 2 Type-C Device Active Optical Cable provides a high-performance connection between USB-C devices and USB-C ports. It supports ultrafast data transfer speeds of up to 10 Gbps and features a reversible USB-C connector for easy, convenient insertion. With its high-capacity delivery of data, video, and power, this AOC cable is an ideal solution for digital signage and retail/Point-of-Sale applications.

Contact to Seller
  • USB-C male to USB-C male for connecting to USB-C device ports
  • Overcomes the USB-C distance limitation for power, data, and video without signal loss; great for digital signage, retail/Point-of-Sale, and more
  • USB 3.2 Gen 2 compliant, supporting SuperSpeed+ transfer rates up to 10 Gbps; backward compatible with USB 3.0/USB 2.0
  • Fiber and copper-wire hybrid for a thinner cable, ideal for installation in tight and narrow spaces
  • USB-C compliance with DisplayPort 1.4 Alternate Mode (DP Alt Mode) for resolutions up to 4K@30Hz on supported devices and displays
  • Supports USB Power Delivery (PD) function up to 60 W and current up to 3 A
  • Foil, braid, and fiber triple shielding to reduce EMI and other interference sources
  • Aramid fiber components for maximum strength and heat resistance
  • Bus-powered - no external power required
  • Plug-and-play installation; Windows®, macOS®, Android™, iOS®, Chrome OS®, iPadOS® and Linux® compatible
Download Product catalog
Two USB-C 24-pin males
24/28 AWG
Triple shielding: aluminum foil, braid, and aramid fiber
Fiber: OM3
Molded TPE boot with strain relief
Die-cast zinc alloy connector material
Jacket OD: 6.5 mm (2.56 in.)
Bend radius: 60 mm (2.36 in.)
Length: 7.5 m (25 ft.)
Net weight: 650 g (1.43 lbs.)
Gross weight: 750 g (1.65 lbs.)
Electrical
Withstanding voltage: 300.0 V DC, 10 ms
Insulation resistance: 5 MOhm
Contact resistance: 2 Ohm
Supported current: 3.0 A (max.)
Supported voltage: 20.0 V (max.)
Operating temperature: -10 to 50°C (14 - 122°F)
Storage temperature: -20 to 60°C (-4 to 140°F)
Humidity (non-condensing): 10 - 85%
USB 3.2 Gen 2 Type-C Active Optical Cable (USB-C Male to Male)
