Ultimatte 12 8K

Ultimatte 12 8K is an advanced real-time compositing processor designed for keying live action video with next-generation broadcast graphics, virtual sets, and more. Ultimatte 12 8K features new algorithms and color science, incredible edge handling and color separation, amazing color fidelity, and better spill suppression than ever before. The high-performance Quad Link 12G-SDI design gives you the power to work in HD, Ultra HD, and incredible 8K with sub-pixel processing for an amazing image.

Contact to Seller

Composite Sources

Foreground

4 x 12G-SDI In with Loop Out

Background

4 x 12G-SDI In with Loop Out

Still from Media Pool

Background Matte

4 x 12G-SDI In with Loop Out

Internal Window

Still from Media Pool

Garbage Matte

4 x 12G-SDI In

Internal Window

Still from Media Pool

Holdout Matte

4 x 12G-SDI In

Internal Window

Still from Media Pool

Layer

4 x 12G-SDI In with Loop Out

Still from Media Pool

Layer Matte

4 x 12G-SDI In with Loop Out

Internal Window

Still from Media Pool

Composite Outputs

Fill

4 x 12G-SDI

Matte

4 x 12G-SDI

Program

4 x 12G-SDI

Talent

4 x 12G-SDI

Media Pool

Background Still Image Formats

TGA, TIFF, BMP, PNG, JPG.

Background with Alpha Still Image Formats

TGA, TIFF, BMP.

Layer Image Still Image Formats

TGA, TIFF, BMP, PNG, JPG.

Layer with Alpha Still Image Formats

TGA, TIFF, BMP.

Garbage Matte Still Image Formats

TIFF, BMP, PNG, JPG.

Holdout Matte Still Image Formats

TIFF, BMP, PNG, JPG.

Media Pool Memory

6GB non-volatile internal storage.



Connections

SDI Video Inputs

32

SDI Video Outputs

20

SDI Video Loop Outputs

20

reclocked SD, HD, Ultra HD, 8K for corresponding inputs.

SDI Rates

270Mb, 1.5G, 3G, 6G, 12G.

Video Input Re-Sync

On all inputs.

Reference Connections

1 x BNC In, 1 x BNC Out.

Tri-Sync or Black Burst.

GPIO

DE15

Ethernet

Up to 10Gb/s for device control and loading stills into Media Pool.

Computer Interface

1 x USB-C 3.0 for device configuration and software updates.
