SL-240C Compact 16–Port Master / Room Controller
The SL-240C is a compact PoE-powered master room controller featuring 4 bidirectional RS-232, 4 IR, 4 GPI/O, and 4 relay ports. It controls AV equipment, lighting, screens, shades, and other devices, with expandable remote I/O through Kramer Ethernet control gateways.
- Supported by Kramer Control
- Scalable & flexible control
- Bidirectional RS–232 & IR with learning capability
- GPI/O & relay control
- Power over Ethernet
- Supported by: Kramer Control Only
| BIDIRECTIONAL PORTS | 4 RS−232 serial on 3−pin terminal blocks, 4 GPI/O on 2−pin terminal blocks, 1 Ethernet on an RJ−45 connector, 1 mini-USB connector for firmware upgrade |
| INPUTS | 1 built−in IR sensor (for learning) |
| OUTPUTS | 4 IR outputs and 4 relays on 2−pin terminal block connectors |
| INDICATORS | LED indicator for each port and function |
| PROCESSOR SPEED | 1GHz |
| MEMORY | 512MB RAM, 4GB Flash |
| POWER CONSUMPTION | 5V DC, 2A |
| POWER SOURCE | PoE (for extra power resiliency, connect to the optional 5V DC power supply) |
| Product Dimensions | 19.00cm x 11.60cm x 2.70cm (7.48" x 4.57" x 1.06" ) W, D, H |
| Product Weight | 0.4kg (1.0lbs) approx |
