PT-102AN 1:2 Stereo Audio Distribution Amplifier
The PT-102AN is a high-performance audio distribution amplifier that accepts one unbalanced stereo audio input and distributes the signal to two identical stereo outputs for reliable audio signal distribution.
- Level (Gain) Controls.
- S/N Ratio — 85dB.
- Ultra–Compact Pico TOOLS™ — 4 units can be rack-mounted side–by–side in a 1U rack space with the recommended rack adapter.
| INPUT | 1 unbalanced stereo audio on a 3.5 mm mini-jack |
| OUTPUTS | 2 unbalanced stereo audio on 3.5 mm mini-jacks |
| MAX. OUTPUT LEVEL | 5Vpp |
| BANDWIDTH (-3dB) | >100kHz |
| S/N RATIO | 85dB @1kHz |
| CONTROLS | Level: −55dB to +20dB |
| COUPLING | AC |
| AUDIO THD + NOISE | 0.01% @1kHz |
| AUDIO 2nd HARMONIC | 0.004% @1kHz |
