The 4K Multi-view switcher is a seamless video scaler designed to enable a true 4K display. The switcher features four HDMI inputs and one HDMI output, which allows you to display four video sources on one display. It also provides a line input, 1 mix input, 1 SPDIF output, and 1 analog output for audio processing. Control is quick and comprehensive, whether you are using the front panel, the remote control, RS232 commands, or the fully featured web GUI
-
4 HDMI inputs, 1 HDMI output.
-
Supports 4K30Hz 4:4:4, HDCP 2.2.
-
Seamless switch between 4 input ports.
-
Auto Scaler in each source input.
-
Supports audio embedding and mixing.
-
Supports audio de-embedding.
-
Auto-switching at a single window.
-
Cycles through the windows from A to D by the swap button
-
Based on FPGA Technology, the layout and size of the windows can be customized
| Video Input | (4) HDMI IN (1~4) |
| Video Input Connector | (4) Type-A female HDMI |
| HDMI Input Resolution | Up to 4K30Hz 4:4:4 |
| Video Output | (1) HDMI |
| Video Output Connector | (1) Type-A female HDMI |
| HDMI Output Resolution | Up to 4K30Hz RGB |
| HDMI Standard | HDMI 1.4 |
| HDCP Version | Up to HDCP 2.2 |
