The MP-NL1208D Digital Sound Processor (DSP) is a professional audio processing solution designed for conference rooms, auditoriums, commercial installations, and live sound applications. Featuring advanced DSP algorithms, intuitive drag-and-drop programming, real-time signal visualization, Acoustic Echo Cancellation (AEC), intelligent noise suppression, automatic mixing, matrix routing, and comprehensive remote control, it delivers exceptional audio clarity, flexibility, and reliable system performance for modern AV environments.
-
Powerful 32-bit Floating-Point DSP Processing
-
Drag-and-Drop DSP Programming Software
-
Real-Time Signal Flow Visualization (WYSIWYG)
-
Acoustic Echo Cancellation (AEC)
-
Intelligent Noise Suppression (NS)
-
Automatic Gain Control (AGC)
-
Automatic Microphone Mixer (Gain Sharing & Threshold Mixing)
-
Automatic Feedback Suppression (Adaptive Notch Filters)
-
31-Band Graphic EQ & Parametric Equalizer
-
High-Pass & Low-Pass Filters (Bessel, Butterworth & Linkwitz-Riley)
-
Matrix Audio Routing & Mixing
| Processor | ADI SHARC 21489(x2) |
| Sampling Rate/Bit Depth | 48K/24bit |
| Input Gain | 0/3/6/9/12/15/18/21/24/27/30/33/36/39/42/45/ 48 dBu |
| Phantom Power | 48V |
| Frequency Response (20~20KHz) | ±0.3dB |
| Maximum Level | +18dBu |
| THD + Noise | 0.003%4dBu |
| Dynamic Range | 113 dB |
| Background Noise (A-weighted) | -91 dB |
| Common Mode Rejection Ratio 60Hz | 80dB |
