This model is perfect for connecting HDMI cameras and computers to professional SDI equipment! You get two 3G-SDI outputs, which can be set to level A or level B formats. Unlike cheap converters, it even supports feature film video formats including 1080p24, 1080p47.95, and 1080p48.
Standards
|
SDI Video Standards |
525i59.94 NTSC, 625i50 PAL |
|
HD Video Standards |
720p50, 720p59.94, 720p60 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p47.95, 1080p48, 1080p50, 1080p59.94, 1080p60 1080i50, 1080i59.94, 1080i60 |
|
SDI Compliance |
SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 424M, SMPTE 425M |
|
SDI Video Rates |
SDI video connections are switchable between standard definition and high definition, and user selectable level A and B for 3G‑SDI via setup utility. |
|
SDI Color Precision |
4:2:2 |
|
SDI Color Space |
YUV |
|
SDI Auto Switching |
Automatically detects SD, HD and 3G-SDI |
|
HDMI Video Standards |
525i29.97 NTSC, 625i50 PAL 720p50, 720p59.94, 720p60 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p47.95, 1080p48, 1080p50, 1080p59.94, 1080p60 1080i50, 1080i59.94, 1080i60 |
|
HDMI Color Precision |
4:2:2 |
|
HDMI Color Space |
YUV |
Connections
|
SDI Video Outputs |
2 x SD, HD or 3G‑SDI. Automatically matches the HDMI input. |
|
HDMI Video Inputs |
HDMI Type A in. |
|
Multi Rate Support |
Auto detection of SD or HD. |
|
Updates, Configurations and Power |
USB Type‑C. |
|
Reclocking |
Yes |
