MC3-2H-2H

MC3−2H−2H is part of Kramer’s high−end modular matrixes family of solutions. It is a high−performance two−port HDMI input and two−port HDMI output card which is part of the compatible modular matrices multi−signal cards family. One or more MC3−2H−2H units can flexibly occupy any of the matrix card slots. Its input signals are independently switched by the modular matrix to any of the matrix output ports, and any matrix input signals are independently switched to its scaling output ports.

Contact to Seller
  • 2 HDMI input ports, 2 HDMI output ports with HDMI 2.0b (4K60 4:4:4), CEC, and HDCP 2.3
  •  Support scaling, fast switching, and clean transition, switching time is less than 1.2s.
  •  HDMI output, ARC audio, flexible routing support
  •  Support online FW upgrade on the webpage
  •  Support the CEC gateway independently per input/output port
  •  The card is hot swappable
Download Product catalog

Inputs
  • 2 HDMI: On HDMI connectors

Outputs
  • 2 HDMI: On HDMI connectors

Video
  • Max Data Rate: 18Gbps (6G per channel)
  • Max Resolution: 4096x2160@60Hz (4:4:4) 24bpp

Switching Time
  • < 1.2 seconds, not flickering or loss

General
  • Product Dimension: 25.50cm x 13.00cm x 2.00cm (10.04" x 5.12" x 0.79")
  • Product Weight: 0.4kg (0.9lbs) approx
  • Shipping Dimensions: W, D, H: 29.50cm x 16.50cm x 5.30cm (11.61" x 6.50" x 2.09")
  • Shipping Weight: 0.5kg (1.1lbs) approx

Product Dimensions
  • 25.50cm x 13.00cm x 2.00cm (10.04" x 5.12" x 0.79" ) W, D, H
