The most compact model of HyperDeck Studio is based on the Teranex Mini form factor. This modular design means that you can use a Teranex Mini Rack Shelf to rack mount 3 HyperDeck Studio HD Minis in a single rack unit, or you can combine them with other products such as switchers, converters, or streaming processors. It might be small, but you still get powerful features, such as 3G-SDI in and out, HDMI output, dual SD card media slots, built-in sync and timecode generators, front panel controls, and both AC and DC power inputs. You can even connect the USB to a computer, as HyperDeck Studio HD Mini works like a webcam, so you can use any video software!
Standards
|
SD Video Standards |
525i59.94 NTSC, 625i50 PAL |
|
HD Video Standards |
720p50, 720p59.94, 720p60 1080i50, 1080i59.94, 1080i60 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30 |
|
2K DCI Video Standards |
2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI, 2Kp29.97 DCI, 2Kp30 DCI |
|
SDI Compliance |
SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 424M, SMPTE 425M level A and B, SMPTE 2084and SMPTE 2108‑1. |
|
SDI Metadata Support |
HD RP188 and closed captioning CEA‑708. HDR Metadata supported on SDI. |
|
Supported HDMI Formats |
525i59.94 NTSC, 625i50 PAL, 720p50, 720p59.94, 720p60, 1080i50, 1080i59.94, 1080i60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI, 2Kp29.97 DCI, 2Kp30 DCI |
|
Audio Sampling |
Television standard 24‑bit, 48 kHz sample rate. |
|
Video Sampling |
4:2:2 YUV |
|
Color Precision |
10‑bit |
|
Color Space |
REC 601, REC 709, REC 2020. |
|
HDR Support |
Hybrid Log‑Gamma, ST2084 300, ST2084 500, ST2084 800, ST2084 1000, ST2084 2000, ST2084 4000, ST2084 |
|
Multi Rate Support |
Auto detection of SD and HD. |
Media
|
Media |
2 x SD card slots 1 x USB-C 3.0 expansion port for external recording of SD, HD and 2K DCI. |
|
Media Type |
UHS-I and UHS-II SD cards. |
|
Media Format |
Can format media to ExFAT (Windows/Mac)or HFS+ (Mac) file systems. |
Control
|
Built-in Control Panel |
8 buttons for transport and device control with search dial and 2.2-inch color display. |
|
External Control |
RS-422 deck control, SDI start/stop, timecode run. Includes Blackmagic HyperDeck Ethernet Protocol. Supports remote FTP file upload. |
Connections
|
SDI Video Inputs |
1 |
|
SDI Video Outputs |
1 |
|
SDI Rates |
270Mb, 1.5G, 3G. |
|
HDMI Video Outputs |
2.2-inch LCD |
|
Timecode Connections |
1 x BNC In, 1 x BNC Out. |
|
Reference Connections |
1 x BNC In, 1 x BNC Out. Tri-Sync or Black Burst. |
|
SDI Audio Inputs |
16 channels embedded audio. |
|
HDMI Audio Outputs |
8 channels of embedded audio. |
|
Remote Control |
1 x RS-422 In. |
|
Recorder Configuration |
Via user interface or Blackmagic HyperDeck Ethernet Protocol. |
|
Ethernet |
1Gb/s |
|
Computer Interface |
1 x USB Type-C 3.0 (up to 5Gb/s) forexternal drive recording, webcam out, software configuration and updates. |
