FC-102Net Encoder & PoE Acceptor

The FC-102Net is a compact 2-channel Dante audio encoder featuring two balanced mono audio inputs for connecting microphones, laptops, and media players to a Dante network. It supports both line-level and microphone-level signals, with selectable 48V phantom power for each input. The device is powered via Power over Ethernet (PoE) using a standard PoE network switch.

Contact to Seller
  • Dante Network Interface.
  •  PoE Acceptor.
  •  Interoperability — Supports AES67 and Dante, allowing high–performance interoperability between IP–based audio networking systems.
  •  Inputs — 2 balanced mono audio on 3–pin terminal blocks.
  •  Output — 2 Dante channels on an RJ–45 connector.
  •  Output Volume Control.
Download Product catalog
Inputs 2 Balanced Mono Mic / Line Level Source On 3−pin terminal blocks
Ports

1 Dante on an RJ−45 connector

1 RS-232 on a 3−pin terminal block
User Interface Control Dante IP control matrix, Kramer Protocol 3000 via RS−232, audio input configuration DIP switches, reset button
Power Source: 48V DC (PoE). Consumption 100mA
Enclosure Size PicoTOOLS®
Environmental Conditions Operating Temperature 0° to +40°C (32° to 104°F)
STANDARDS COMPLIANCE Safety CE, Environmental RoHS, WEEE
Product Dimensions 6.22cm x 5.18cm x 2.44cm (2.45" x 2.04" x 0.96" ) W, D, H
