Blackmagic PYXIS Monitor is a versatile 5″ HDR touchscreen monitor with full camera control that can be mounted almost anywhere. It provides an additional monitoring and camera control option that can be mounted anywhere, so it’s perfect for use when rigging or other accessories block Blackmagic PYXIS’ internal display. The bright 1500 nit high-brightness screen makes monitoring easy, even in bright sunlight, and includes a removable sunshade that also folds up to protect the monitor. Blackmagic PYXIS Monitor is easy to set up with a single USB-C cable connection for video, power, and camera control.
Features
|
Display Size |
5 inch. |
|
Display Resolution |
Full 1920 x 1080. |
|
Display Type |
LCD capacitive touchscreen. |
|
Display Brightness |
1500 nits. |
|
Frame Rates |
Up to 60fps. |
|
Tally |
Rear-facing LED tally light. |
|
Accelerometer |
Automatically rotates the image when the monitor is mounted upside down. |
Mounting
Mounting Points
1 x 1/4-20 bottom mounting point with ARRI locating pin pattern.
2 x M4 bottom mounting points.
1 x 1/4-20 side mounting point with ARRI locating pin pattern.
2 x M4 side mounting points.
Control
|
On Screen Controls |
Tap screen to control Monitor Overlays, Frame Rate, Shutter, Iris, Timecode,ISO, White Balance, Tint, Power,Record Start/Stop, Media, Audio,Focus Zoom, Digital Slateand camera menus. |
|
Button Controls |
Includes F1, F2, F3 assignable functionbuttons to recall preset parameters ortoggle functions. |
|
Function Button Presets |
FPS: Preset Value Iris: Preset Value WB: Preset Value ISO: Preset Value Shutter: Preset Value |
|
Function Button Toggle |
Clean Feed Status Text Display LUT Frame Guides Focus Assist False Color Zebra Grid Safe Area Guide Off Speed Rec Focus Zoom Focus Record Auto White Balance Color Bars Playback False Color + Zebra OIS Stream Still |
