Blackmagic Micro Studio Camera 4K G2 is an amazing, broadcast-quality live production camera in a tiny body. The Four Thirds sensor has 13 stops of dynamic range, incredible low-light performance, and produces stunning Ultra HD images in all lighting conditions. 12G-SDI Micro BNC connectors support 10-bit uncompressed video up to 2160p60 and 2-channel audio on the output. The input supports tally, camera control, control of the built-in color corrector, plus lens control, from an ATEM switcher. Or when using an ATEM Mini switcher, the HDMI connector will output 1080 and support all control features. Plus, it's even a Hollywood-quality cinema camera because it can record Blackmagic RAW to external USB-C drives. With multiple mounting points, place Blackmagic Micro Studio Camera 4K G2 where no other camera will go!
|
Effective Sensor Size |
17.78mm x 10mm (Four Thirds) |
|
Lens Mount |
Active MFT Mount. |
|
Lens Control |
Iris, focus, zoom on supported lenses. |
|
Dynamic Range |
13 Stops. |
|
Dual Native ISO |
0dB and 18dB gain. |
|
Sensitivity at 0dB Gain |
f11 with 2160p59.94. f12 with 2160p50. at 2,000 lux with 89.9% reflectance. |
|
Storage Type |
1 x USB‑C 3.1 Gen 1 expansion port for external media. |
|
Recording Formats |
Blackmagic RAW 3:1, 5:1, 8:1, 12:1, Q0, Q1, Q3 and Q5 in Ultra HD 3840 x 2160 at the selected frame rate. |
|
Storage Rates |
Storage rates are based on 30 frames per second. |
|
3840 x 2160 (Ultra HD) |
Blackmagic RAW 3:1 - 127 MB/s Blackmagic RAW 5:1 - 77 MB/s Blackmagic RAW 8:1 - 48 MB/s Blackmagic RAW 12:1 - 32 MB/s Blackmagic RAW Q0 - 96 to 190 MB/s Blackmagic RAW Q1 - 64 to 153 MB/s Blackmagic RAW Q3 - 43 to 109 MB/s Blackmagic RAW Q5 - 26 to 64 MB/s |
