The Blackmagic Cloud Store is a very fast, high-capacity network disk that's designed to handle large media files used on Hollywood feature films. The design uses advanced flash memory, so it easily handles lots of simultaneous users. Plus, it's extremely easy to set up!
Storage
|
Storage Type |
M.2 NVMe SSD |
|
Total Capacity |
20TB or 80TB |
|
Redundancy |
RAID 5 distributed parity |
|
External Storage |
USB Disks |
|
External Storage Format |
ExFAT (Windows/Mac) or HFS+ (Mac) file systems. |
Displays
|
HDMI Monitor Out Standards |
1080p50, 1080p59.94, 1080p60. |
|
Monitor Out Displays |
Device Name, storage capacity and use, Cloud Sync status, User Activity, Hardware Status, storage map, network data rate graphs. |
|
Status Indicator |
Underside white glow indicating normal operation or red glow indicating disk or power supply fault. |
Connections
|
10G Ethernet Ports |
4 x 100/1000/10G BASE-T |
|
1G Ethernet Ports |
2 x 100/1000 BASE-T |
|
Ingest USB-C Port |
1 x USB 3.0 (up to 5Gb/s). Automatically transfers files from USB drive to Cloud Store. |
|
Backup USB-C Port |
1 x USB 3.0 (up to 5Gb/s). Automatically backs up files from Cloud Store to USB drive. |
|
HDMI Monitor Outputs |
1 |
|
Computer Interface |
Ethernet for shared file access, configuration and software updates. USB-C for configuration and software updates. |
