The ATEM Streaming Bridge is a video converter that lets you receive an H.264 stream from any ATEM Mini Pro and convert it back to SDI and HDMI video. This means you can send video to remote locations around your local Ethernet network, or via the internet globally! That's possible because it uses advanced H.264 codecs for higher quality at very low data rates. Imagine broadcasters and bloggers collaborating on shows and creating global networks of ATEM Mini Pro remote broadcast studios. Setup is easy, as the ATEM software utility can create setup files that you can email to remote ATEM Mini Pro studios. ATEM Streaming Bridge is the perfect way to use ATEM Mini Pro as a remote broadcast studio!
Standards
|
SDI Video Standards |
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080i50, 1080i59.94, 1080i60 |
|
HDMI Video Standards |
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60 |
|
SDI Compliance |
SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 424M‑B, SMPTE 425 Level A and Level B. |
|
SDI Video Sampling |
4:2:2 |
|
SDI Audio Sampling |
Television standard sample rate of 48 kHz and 24-bit. |
|
SDI Color Precision |
10-bit |
|
SDI Color Space |
YUV |
Connections
|
SDI Reference Inputs |
1 x 3G-SDI |
|
SDI Video Outputs |
2 x 3G-SDI |
|
SDI Audio Outputs |
2 Channels embedded in HD-SDI. |
|
HDMI Video Output |
HDMI type A out. |
|
HDMI Audio Outputs |
2 Channels embedded in HDMI. |
|
SDI Rates |
1.5G, 3G. |
|
Reference Input |
Black burst and Tri‑Sync. |
