8412P 20 AWG ,PLENUM , MIC CABLE
20 AWG, 2 stranded (7x28) high-conductivity TC conductors, FEP Teflon® insulation, TC braid shield (85%), FEP Teflon® jacket.
Conductor
| Size | Stranding | Material |
| 20 | 7x28 | TC - Tinned Copper |
Insulation
| Material | Nom. Insulation Diameter | Color Code |
| FEP - Fluorinated Ethylene Propylene | 074 in (1.9 mm) | Dark Blue, Clear |
Electricals
| Nom. Conductor DCR | Nom. Capacitance Cond-to-Cond | Nom. Capacitance Cond-to-Other (Conds + Shield) | Nom. Inductance | Nom. Velocity of Prop. |
| 9.5 Ohm/1000ft (31 Ohm/km) | 18.4 pF/ft (60.4 pF/m) | 33.1 pF/ft (109 pF/m) | 0.2 µH/ft (0.66 µH/m) | 70% |
